VCLB-5K-D01 Series Low Voltage Rack Mounted Lithium Battery
- Unique Design.
- LED Display.
- Flexible Capacity.
- Easy Installation.
- Safe &Reliable.
Catalogue
Contact support
EmailRack Mounted Lithium-ion Energy Storage Battery Overview
The 51.2V 100Ah single module low voltage rack mounted lithium ion battery is a state-of-the-art energy storage solution designed to meet the diverse energy needs of both residential and commercial settings.
Features of 51.2V 100Ah Single Module Rack Mounted Lithium-ion Battery
1. Unique Design
Rack mount.
2. LED Display
SOC, Battery Status.
3. Flexible Capacity
Max.15pcs in Parallel to extend capacity.
4. Easy Installation
Quick plug in +/- and parallel connection.
5. Safe &Reliable
Lithium Iron Phosphate (LFP) Cell.
6. CertificatesCB , UN38.3, MSDS, CE EMC UL1973,UL9540A.
Applications for 51.2V 100Ah Single Module Rechargeable Lithium Ion Battery
The 51.2V 100Ah rack mounted lithium-ion battery is versatile and suitable for a wide range of applications, including:
- Residential solar energy storage
- Space-constrained commercial and industrial environments
- Backup power solutions for homes and small businesses
- Demand charge management for commercial facilities
- Integration with electric vehicle (EV) charging stations
- Support for renewable energy microgrids
Specifications
| Nominal Voltage | 51.2V |
|---|---|
| Rated Capacity | 100Ah |
| Energy | 5120Wh |
| Battery Impedance | ≤50mΩ |
| Charging Cut-off Voltage | 56.16V |
| Discharge Cut-off Voltage | 45.6 V |
| Recommend Charge Current | 0.5C 50A |
| Max Charge Current | 0°C ~ 15°C: 20A; 15°C ~ 45°C: 50A |
| Max Continue Discharge Current | 100A, -20°C~60°C ; 65±20%RH |
| Operating Temperature Range | –20~60℃ |
| Storage Environment (50% state of charge) |
20°C ~ 45°C in three months; 25±3°C over three months; Humidity:65±20%RH |
| Environment | Indoor |
| Installation | Rack Mount |
| Cell Technology | Lithium-iron phosphate (LiFePO4) |
| Life Cycle | 6000 times @80%DOD |
| Cooling | Natural cooling |
| Protection Rating | IP20 |
| Certificates | CB, IEC62619, UL1973, UL9540A, UKCA, CE-EMC,CE-GPSD,UN38.3, MSDS |
| Dimension | 550*440*130mm(3U) |
|---|---|
| Battery Net Weight (Approx.) | 47.2kg |
